PTZ-IP Conference Cameras
The PTZ 12x72 / PTZ 20x60 conference cameras integrate with the Q-SYS Platform and Q-SYS bridging peripherals like the Q-SYS I/O-USB Bridge or directly to the Q-SYS Core 110f processor to deliver professional quality conference video feeds alongside industry leading audio processing. These cameras are intended for small- and medium-sized rooms, and utilize soft-codec conferencing or computer-based capture.
Note: This topic provides an overview of the PTZ conference camera peripherals. For installation instructions, see the Quick Start Guide online.
- Conference video for the Q-SYS AV-to-USB Bridging Solution
- Distribute video via the Q-LAN™ network anywhere it is needed
- Resolutions up to 1080p/60
- Image rotation controls to allow for inverted mounting
- Motorized Pan, Tilt and Zoom (PTZ) provides complete room coverage and privacy
- Auto Exposure, Auto Focus and Auto White Balance modes
- Native custom camera interfaces through Q-SYS Designer Software
- Includes wall mount for simple installation
Add the PTZ cameras to your design inventory from the Peripherals category. The following components are available for the PTZ-12x72 and PTZ-20x60:
Front Panel
- STATUS LED –
- Green LED
- Off indicates the camera is in STANDBY mode, network streams are off.
- On indicates the camera is streaming video over the network.
- Blinking indicates the ID mode is on
- POWER LED -
- Blue LED
- On indicates the camera has power applied
- Off indicates the camera has no power applied
Rear Panel
- Label
- Model: PTZ-12x72 or PTZ-20x60
- MAC Address
- Serial Number (on the bottom of the unit)
- ID Button – Press to identify this piece of equipment in Q-SYS Designer, and Configurator. The green STATUS LED, on the front panel, blinks when in ID mode.
- FACTORY RESET pin-hole – Use a paperclip or similar object to insert and press and hold the reset button for 5 seconds. This resets all parameters to the factory defaults.
- Kensington™ Lock slot – Security cable not supplied.
- LAN / POE – Q-SYS Gigabit Ethernet port / CAT5e or better / RJ45 / connect to the Q-LAN™ network switch with Power over Ethernet
- HDMI – Camera output to various video formats setup by the users through Q-SYS Designer or a Q-SYS UCI (User Controlled Interface)
Note: When a video format is selected, it is used by both the HDMI and 3G SDI outputs.
- 3G SDI – Camera output to various video formats setup by the user. Setup is through Q-SYS Designer or a Q-SYS UCI
- SERVICE – No user-accessible functionality.
- DC 12 V – Connect an external power supply (not included). Supply to be rated at 12 V / 1 A, center-pin positive, outside barrel negative. Use only a Class 2 / LPS Power Supply.
|
PTZ-12x72 |
PTZ-20x60 |
Image Sensor |
1/2.7", Low Noise CMOS Image Sensor |
|
Lens characteristics (wide to tele) |
||
Optical zoom Horizontal Field of View Vertical Field of View |
12x, f=3.5mm to 42.3mm, F1.8 to F2.8 72.5° to 6.9° 44.8° to 3.9° |
20x, f=4.42mm to 88.5mm, F1.8 to F2.8 60.7 to 3.36° 34.1° to 1.89° |
Minimal Illumination |
0.5 lux at F1.8 (AGC On) |
|
Noise Reduction |
2D and 3D |
|
S/N Ratio |
≥ 55dB |
|
Pan / Tilt Angle and Speed |
Pan: ±170° rotation, speed: 1.7° to 100°/sec, Tilt: -30° to +90° rotation, speed: 1.7° to 69.9°/s |
|
Ceiling Mountable |
Image rotation for ceiling mounting set in Q-SYS Designer. Ceiling mount bracket accessory available. |
|
HD Video Outputs |
HDMI v1.3 and 3G-SDI |
|
Ethernet |
100BaseTX / 1000BaseT |
|
Video Resolutions |
||
HDMI / SDI: Network (30fps, 16:9): |
1080p – 60/50/30/25 | 1080i – 60/50 | 720p – 60/50/30/25 1080p, 720p, 576p, 360p, 270p, 180p |
|
Network Bandwidth |
IP Stream 1, Motion JPEG: IP Stream 2, H.264: |
|
Input Voltage |
DC 12V / PoE (802.3af) Class 3 |
|
Current Consumption |
1.0A (max) |
|
Operating Temperature |
-10°C - 40°C (14°F - 104°F), Indoor use only |
|
Storage Temperature |
-40°C - 60°C (-40°F - 140°F) |
|
Power Consumption |
12W (max) |
|
Shipping Dimensions (H W D) |
252mm x 235mm x 235mm (10in x 9.25in x 9.25in) |
|
Weight |
||
Shipping Camera |
2.5kg (5.6lb) 1.4Kg (3.0lb) |
For more information, and to see a list of related documentation, visit the PTZ-IP Conference Cameras product page on the QSC website.
